| Priključak za vodu sa zadnje ili gornje strane kroz montažne rupe | G1/2 " |
| Funkcionalni opseg pritiska vode | 0,05 – 1,6 MPa |
| Preporučeni opseg pritiska vode | 0,3 – 0,5 MPa |
| Veliko ispiranje | 6 – 9 l |
| Malo ispiranje | 2,5 – 3,5 l |
| Uobičajena postavka velikog ispiranja | 6 l |
| Uobičajena postavka malog ispiranja | 3 l |
| Higijenska rezerva | 3 l |
| Količina vode u cisterni | 9 l |
| Količina (pakovanje) | 1 kom |
| Količina (paleta) | 20 kom |
| Dimenzije (komad) | 1050×480×140 mm |
| Dimenzije (pakovanje) | 1050×480×140 mm |
| Težina (komad) | 4,8719 kg |
| Težina (pakovanje) | 4,8719 kg |
| Težina (paleta) | 117,438 kg |
| M0005-ND | Water supply ring A100 |
| M0017C-ND | Inlet fill valve bracket |
| M0080-ND | Sleeve cover for WC systems |
| M0243-ND | Nut for angle valve bracket |
| M0506-ND | WC cistern hinge support |
| M0507-ND | WC cistern hinges |
| M0603-ND | Cuff |
| M0604-ND | Inlet sealing |
| M0612-ND | Perforated tape straight 17/6.5 |
| M0613-ND | Holder |
| M0615-ND | Holder lock |
| M954-ND | Mechanism complete for WC systems |
| M959-ND | Set for exchange of inlet fill valve |
| MN0091-ND | Frame sleeve for WC systems |
| MN0092C-ND | Frame for WC system sleeve |
| MN0115-ND | Pipe with O-ring for WC systems |
| MN0867-ND | Inner plate for WC tablet dispenser |
| MN1238-ND | Water supply elbow AM112 |
| P165-ND | Angle valve with bracket and nut |
| P176-ND | Tablet ejector and insert - set |
| P211-ND | Shut valve Schell replacement kit |
| S0956-ND | Rosette DN40 |
| Z0007-ND | Wrapping seal DN60/40 |
| Šifra proizvoda | EAN | Tehnički list | ||
|---|---|---|---|---|
| AM112 | 8595580550493 |  |
